The investigation of fluorescence lifetime became an important tool in biology and medical science. So far, established methods of fluorescence lifetime measurements require the illumination of the investigated probes with pulsed or amplitude-modulated light. In this paper, we examine the limitations of an innovative method of fluorescence lifetime using time-frequency correlated photons generated by a continuous-wave source. For this purpose, we investigate the lifetime of IR-140 to demonstrate the functional principle and its dependencies on different experimental parameters. We also compare this technique with state-of-the-art FLIM and observed an improved figure-of-merit. Finally, we discuss the potential of a quantum advantage.

The rise of micro/nanooptics and lab-on-chip devices demands the fabrication of three-dimensional structures with decent resolution. Here, we demonstrate the combination of grayscale electron beam lithography and direct forming methodology to fabricate antimony sulfide structures with free form for the first time. The refractive index of the electron beam patterned structure was calculated based on an optimization algorithm that is combined with genetic algorithm and transfer matrix method. By adopting electron irradiation with variable doses, 4-level Fresnel Zone Plates and metalens were produced and characterized. This method can be used for the fabrication of three-dimensional diffractive optical elements and metasurfaces in a single step manner.

Entangled two-photon absorption can enable a linear scaling of fluorescence emission with the excitation power. In comparison to classical two-photon absorption with a quadratic scaling, this can allow fluorescence imaging or photolithography with high axial resolution at minimal exposure intensities. However, most experimental studies on two-photon absorption were not able to show an unambiguous proof of fluorescence emission driven by entangled photon pairs. On the other hand, existing theoretical models struggle to accurately predict the entangled two-photon absorption behavior of chemically complex dyes. In this paper, we introduce an approach to simulate entangled two-photon absorption in common fluorescence dyes considering their chemical properties. Our theoretical model allows a deeper understanding of experimental results and thus the occurrence of entangled two-photon absorption. In particular, we found a remarkable dependency of the absorption probability on the phase-matching temperature of the nonlinear material. Further, we compared results of our theoretical approach to experimental data for Nile Red.

Antimony trisulfide ($Sb_{2}S_{3}$), as an emerging material for integrated photonic devices, has attracted significant attention due to its high index, low loss, and phase-changing property in the optical regime. However, conventional lithography-based fabrication methods involve complex, time-consuming, multistep processes, rendering the photonic application of $Sb_{2}S_{3}$ challenging. Here, we demonstrate that positive-tone fabrication of $Sb_{2}S_{3}$ nanostructures using wet-etch femtosecond laser processing, a straightforward technique for the engraving of micro- and nanoscale structures, can address major fabrication challenges. The patterning mechanism and factors influencing resolution of $Sb_{2}S_{3}$ thin film structures deposited on quartz (transmissive) and gold (reflective) substrates are experimentally investigated and supported by theoretical modelling. Using this approach, the smallest linewidth fabricated is measured at 178 nm. Consequently, multiple test patterns are demonstrated showing versatile functionalities. Functional Fresnel Zone Plates (FZPs) with varying focal length are fabricated and characterized. This study provides a significantly simplified approach for realizing $Sb_{2}S_{3}$ based integrated photonic devices.

In-memory computing is a promising alternative to traditional computer designs, as it helps overcome performance limits caused by the separation of memory and processing units. However, many current approaches struggle with unreliable device behavior, which affects data accuracy and efficiency. In this work, the authors present a new computing method that combines two types of operations,those based on electrical resistance and those based on voltage, within each memory cell. This design improves reliability and avoids the need for expensive current measurements. A new software tool also helps automate the design process, supporting highly parallel operations in dense two-dimensional memory arrays. The approach balances speed and space, making it practical for advanced computing tasks. Demonstrations include a digital adder and a key part of the encryption module, showing both strong performance and accuracy. This work offers a new direction for reliable and efficient in-memory computing systems with real-world applications.
