Ni particle coarsening is a primary degradation mechanism in Ni/YSZ solid oxide cells, limiting the lifespan of these devices. In this study, we demonstrate the use of Scanning 3D X-ray diffraction (S3DXRD) with an unprecedented spatial resolution of 100 nm, to monitor the microstructural evolution within the 3D volume of a solid oxide cell subjected to ex situ heat treatment. Unlike conventional tomography, S3DXRD combines crystallographic information with spatial maps, enabling precise identification of grain boundaries and the determination of local curvature changes in the Ni microstructure. Our study reveals that the Ni phase undergoes significant structural changes during annealing, driven by grain growth. This transformation is characterized by a reduction in local curvature, particularly in regions where grains disappear. We observe that the disappearing grains are the smallest grains in the size distribution and are often located near pores. As a result, the most notable reduction in local curvature occurs at the Ni-pore interface. The quantitative characterization of polycrystalline microstructural evolution in Ni/YSZ system provides new insights into the mechanisms of Ni particle coarsening in SOC devices, potentially guiding strategies to enhance the long-term stability of SOC devices.

Tomographic volumetric 3D-printing (TVP) utilizes a nonlinear photoresponse of polymer precursor to cure all points in a three-dimensional (3D) object in parallel. A key challenge in TVP is to build up dose contrast between in-part and out-of-part points in a lateral plane, which relies on coordinated illumination from various projecting angles. This challenge has mainly been tackled by projection optimization. Here we show that designing material responses to photo-excitation can be a more effective way of addressing this challenge. By introducing a secondary photo-inhibitory species that reacts to external ultraviolet (UV) stimulus, we create a binary photoinhibition (BPI) system that greatly enhances the achievable dose contrast in a lateral plane. We first show that, in theory, combining dose subtraction with sufficient projection angles can guarantee an exact mathematical reconstruction of any greyscale design. We then propose a theoretical framework for BPI, in which a single stationary state with swappable stability can be used to realize dose subtraction. We use oxygen-lophyl radical pair as an approximation to show improvements in print quality enabled by enhanced dose contrast. In situ shadowgraphy shows that BPI improves the lateral patterning with various geometric features, creating differentiable changes in refractive index within 54 um or less. We show qualitative improvements in surface features and internal hollowness in physical prints. The direct impacts of UV light on the formation of positive and negative features on vertical and lateral planes of 5 workpieces are analyzed quantitatively. We conclude that introducing BPI with UV irradiation grants us direct control over the formation of negative features on the lateral plane.

The ability to characterise the three-dimensional microstructure of multiphase materials is essential for understanding the interaction between phases and associated materials properties. Here, laboratory-based diffraction-contrast tomography (DCT), a recently-established materials characterization technique that can determine grain phases, morphologies, positions and orientations in a voxel-based reconstruction method, was used to map part of a dual-phase steel alloy sample. To assess the resulting microstructures that were produced by the DCT technique, an EBSD map was collected within the same sample volume. To identify the 2D slice of the 3D DCT reconstruction that best corresponded to the EBSD map, a novel registration technique based solely on grain-averaged orientations was developed -- this registration technique requires very little a priori knowledge of dataset alignment and can be extended to other techniques that only recover grain-averaged orientation data such as far-field 3D X-ray diffraction microscopy. Once the corresponding 2D slice was identified in the DCT dataset, comparisons of phase balance, grain size, shape and texture were performed between DCT and EBSD techniques. More complicated aspects of the microstructural morphology such as grain boundary shape and grains less than a critical size were poorly reproduced by the DCT reconstruction, primarily due to the difference in resolutions of the technique compared with EBSD. However, lab-based DCT is shown to accurately determine the centre-of-mass position, orientation, and size of the large grains for each phase present, austenite and martensitic ferrite. The results reveals a complex ferrite grain network of similar crystal orientations that are absent from the EBSD dataset. Such detail demonstrates that lab-based DCT, as a technique, shows great promise in the field of multi-phase material characterization.

Strength, ductility, and failure properties of metals are tailored by plastic deformation routes. Predicting these properties requires modeling of the structural dynamics and stress evolution taking place on several length scales. Progress has been hampered by a lack of representative 3D experimental data at industrially relevant degrees of deformation. We present an X-ray imaging based 3D mapping of an aluminum polycrystal deformed to the ultimate tensile strength (32% elongation). The extensive dataset reveals significant intra-grain stress variations (36 MPa) up to at least half of the inter-grain variations (76 MPa), which are dominated by grain orientation effects. Local intra-grain stress concentrations are candidates for damage nucleation. Such data are important for models of structure-property relations and damage.

The development of three-dimensional (3D) non-destructive X-ray characterization techniques in home laboratories is essential for enabling many more researchers to perform 3D characterization daily, overcoming the limitations imposed by competitive and scarce access to synchrotron facilities. Recent efforts have focused on techniques such as laboratory diffraction contrast tomography (LabDCT), which allows 3D characterization of recrystallized grains with sizes larger than 15-20 $\mu$m, offering a boundary resolution of approximately 5$\mu$m using commercial X-ray computed tomography (CT) systems. To enhance the capabilities of laboratory instruments, we have developed a new laboratory-based 3D X-ray micro-beam diffraction (Lab-3D$\mu$XRD) technique. Lab-3D$\mu$XRD combines the use of a focused polychromatic beam with a scanning-tomographic data acquisition routine to enable depth-resolved crystallographic orientation characterization. This work presents the first realization of Lab-3D$\mu$XRD, including hardware development through the integration of a newly developed Pt-coated twin paraboloidal capillary X-ray focusing optics into a conventional X-ray $\mu$CT system, as well as the development of data acquisition and processing software. The results are validated through comparisons with LabDCT and synchrotron phase contrast tomography. The findings clearly demonstrate the feasibility of Lab-3D$\mu$XRD, particularly in detecting smaller grains and providing intragranular information. Finally, we discuss future directions for developing Lab-3D$\mu$XRD into a versatile tool for studying materials with smaller grain sizes and high defect densities, including the potential of combining it with LabDCT and $\mu$CT for multiscale and multimodal microstructural characterization.
